Kinase experiment:

To establish whether PFI-3 intercalates DNA, the compound is assessed using a DNA unwinding assay. PFI-3 (1, 5, or 10 μM), cisplatin, or doxorubicin is incubated with supercoiled pBR322, in the presence of wheat germ topoisomerase I, for 30 min at 37℃. DNA incubated with DMSO in the presence or absence of the enzyme is run as control. After extraction by butanol and chloroform/isoamyl alcohol 24:1, the DNA is run in a 1% (w/v) agarose gel with a 1-kb DNA ladder for 4 hours at 80 V. The gel is then stained with SYBR Safe for 30 min before ultraviolet visualization[2].

PFI 3 is a potent and selective inhibitor of polybromo 1 and SMARCA4 with Kd values of 48 and 89 nM, respectively [1].

Transcription activator BRG1 (SMARCA4) is a member of the SWI/SNF family and regulates transcription. Protein polybromo-1 (PB1, PBRM1) is a BRG1-associated factor and tumor suppressor.

PFI 3 is a potent and selective inhibitor of polybromo 1 and SMARCA4. PFI 3 bound to SMARCA2 and SMARCA4 bromodomains with Kd values of 55 and 110 nM, respectively. PFI-3 (2 μM) inhibited PBRM1 by 70%. In cell-based chromatin binding assays, PFI-3 replaced GFP-tagged SMARCA2 bromodomain in a dose-dependent way with IC50 value of 5.78 μM. PFI-3 was a cell-permeable probe suitable for studying SMARCA2/4 bromodomains. In the SMARCA4-deficient A549, H1299, H157 cell lines, PFI-3 had no anti-proliferative effects and was unable to replace SMARCA2 from chromatin. In THP-1 and MV4-11 leukemic cells, PFI 3 did not induce anti-cancer phenotype [1].

Reference:
[1].  Vangamudi B, Paul TA, Shah PK, et al. The SMARCA2/4 ATPase domain surpasses the bromodomain as a drug target in SWI/SNF mutant cancers: Insights from cDNA rescue and PFI-3 inhibitor studies. Cancer Res, 2015, pii: canres.3798.2015.
